ES101CH4
  1.  Outdoor Methane CH4 Sensor

Outdoor Methane CH4 Sensor
Related Downloads Inquiry cart
Outdoor Protective Design
  • Prevent direct ultraviolet radiation to the sensors
  • Avoid rapid aging of sensors under harsh environmental conditions such as strong winds, rain, and snow
  • The sensor parts are ventilated for truly sensing the changes in external detection parameters
  • Single or multiple parameters both can use small shutter, small size, lightweight and easy to install
Optional IoT Router and Cloud Platform - ThingsMaster
  • Support Modbus to connect optional NBIoT Gateway WR222 for one or many sensors
  • Real-time online monitoring, analysis, reporting
  • Remote cloud security and visual management
CH4 measurement range 0-100% Lower Explosive Limit (LEL)
CH4 resolution 1% LEL
Accuracy ±5% in Full Scale, No Less than 5% Oxygen
Signal output RS485 2-wire output (Modbus protocol)
Stability <7% Signal / Year
Operating Voltage 10~30VDC
Power consumption 0.9W
Working Environment -20-+40°C , 0-95%RH
Response Time ≤15Sec.
Pre-Heat Time ≥ 5Min
Dimension & Installation 85 x110 x 44; Wall Mounting
